TeraFlex JK: Sport Control Arms Kit – 4-Arms (2.5-3” Lift)
JK 4 Door, 2 Door 2.5", 3" Front Lower, Rear Upper Driver, Passenger
1254000
Lengthen the wheelbase and center the rear wheels on your JK Wrangler/Unlimited with the TeraFlex JK: 2” Alpine Rear Stretch Kit.
The additional 2” stretch improves wheelbase characteristics including climbing under extreme conditions as well as rear tire clearance.
The new relocation brackets ensure the rear coil springs (not included) remain vertical to prevent spring bowing.
Although it’s been designed for aftermarket “high-line” fenders, this kit will still work with the factory fender flares.
The additional 2” stretch improves wheelbase characteristics including climbing under extreme conditions as well as rear tire clearance.
The new relocation brackets ensure the rear coil springs (not included) remain vertical to prevent spring bowing.
Although it’s been designed for aftermarket “high-line” fenders, this kit will still work with the factory fender flares.
Pricing:
$541.99
Description
TeraFlex JK: Sport Control Arms provide maintenance-free and dependable performance on JK Wrangler/Unlimited models with 2.5-3” lifts.
Bolts to the factory control arm mounting brackets.
Can be added to any existing suspension lift.
High-quality, dependable, maintenance-free, factory-style bushings provide excellent NVH damping and ride quality.
Fits:
• JK Wrangler (2-door)
• JK Wrangler Unlimited (4-door)
• 2.5-3” Lift
Includes:
Sport Control Arms – Preset:
• Front Lower (# 1252000) – pair
• Rear Upper (# 1252300) – pair
Features & Benefits:
• Preset Sport Control Arms balance caster and pinion angles as well as optimize rear pinion angle and tune anti-squat geometry for proper suspension alignment on 2.5-3” lift kits
• Sport Control Arms are constructed from durable 42mm x 4mm wall DOM tube for maximum strength
• Re-centers axles in the wheel well for proper suspension movement
• Bolts to the factory control arm mounting brackets
• Full range of movement will not restrict articulation or flex off-road
• High-quality, dependable, maintenance-free, factory-style bushings provide excellent NVH (noise, vibration, and harshness) damping and ride quality.
• Premium black e-dipped coating on tube and forged rod end housing provides superior durability and corrosion resistance
• Install and drive simple bolt-on installation – no welding required
• TeraFlex Lifetime Warranty against defects
Sport Control Arm Specs:
JK: Sport Control Arm Kit – Front Lower (# 1252000)
• Tube Diameter & Wall: 1-5/8” X 0.157” (42mm X 4mm)
• Factory Length = 22-5/8”
• Sport Length = 22-13/16”
• Both Ends = 9/16” (14mm) Bolt
• Both Bushings = # 611011
JK: Sport Control Arm Kit – Rear Upper (# 1252300)
• Tube Diameter & Wall: 1-5/8” X 0.157” (42mm X 4mm)
• Factory Length = 17-7/16”
• Sport Length = 17-11/16”
• Both Ends = 9/16” (14mm) Bolt
• Both Bushings = # 611012
Install Time: 2.5 Hours
Configurations:
• Sport Control Arms – Preset:
• 8-Arm (# 1258000)
• 4-Arm (# 1254000)
• Front Upper (# 1252200) – pair
• Replacement Bushing (Both Ends # 611014)
• Front Lower (# 1252000)
• Replacement Bushing (Both Ends # 611011)
• Rear Upper (# 1252300)
• Replacement Bushing (Both Ends # 611012)
• Rear Lower (# 1252100)
• Replacement Bushing (Both Ends # 611011)
Bolts to the factory control arm mounting brackets.
Can be added to any existing suspension lift.
High-quality, dependable, maintenance-free, factory-style bushings provide excellent NVH damping and ride quality.
Fits:
• JK Wrangler (2-door)
• JK Wrangler Unlimited (4-door)
• 2.5-3” Lift
Includes:
Sport Control Arms – Preset:
• Front Lower (# 1252000) – pair
• Rear Upper (# 1252300) – pair
Features & Benefits:
• Preset Sport Control Arms balance caster and pinion angles as well as optimize rear pinion angle and tune anti-squat geometry for proper suspension alignment on 2.5-3” lift kits
• Sport Control Arms are constructed from durable 42mm x 4mm wall DOM tube for maximum strength
• Re-centers axles in the wheel well for proper suspension movement
• Bolts to the factory control arm mounting brackets
• Full range of movement will not restrict articulation or flex off-road
• High-quality, dependable, maintenance-free, factory-style bushings provide excellent NVH (noise, vibration, and harshness) damping and ride quality.
• Premium black e-dipped coating on tube and forged rod end housing provides superior durability and corrosion resistance
• Install and drive simple bolt-on installation – no welding required
• TeraFlex Lifetime Warranty against defects
Sport Control Arm Specs:
JK: Sport Control Arm Kit – Front Lower (# 1252000)
• Tube Diameter & Wall: 1-5/8” X 0.157” (42mm X 4mm)
• Factory Length = 22-5/8”
• Sport Length = 22-13/16”
• Both Ends = 9/16” (14mm) Bolt
• Both Bushings = # 611011
JK: Sport Control Arm Kit – Rear Upper (# 1252300)
• Tube Diameter & Wall: 1-5/8” X 0.157” (42mm X 4mm)
• Factory Length = 17-7/16”
• Sport Length = 17-11/16”
• Both Ends = 9/16” (14mm) Bolt
• Both Bushings = # 611012
Install Time: 2.5 Hours
Configurations:
• Sport Control Arms – Preset:
• 8-Arm (# 1258000)
• 4-Arm (# 1254000)
• Front Upper (# 1252200) – pair
• Replacement Bushing (Both Ends # 611014)
• Front Lower (# 1252000)
• Replacement Bushing (Both Ends # 611011)
• Rear Upper (# 1252300)
• Replacement Bushing (Both Ends # 611012)
• Rear Lower (# 1252100)
• Replacement Bushing (Both Ends # 611011)
