TeraFlex JK: Alpine IR Short Control Arms Kit – 8-Arms (2-4” Lift)
JK 4 Door, 2 Door 3"
1415611
TeraFlex JK: Alpine IR Long Control Arms and Alpine Long Arm Brackets (NOT INCLUDED) provide complete alignment adjustability and dependability for maximum performance on JK Wrangler/Unlimited models with 3–6” lifts. Can be added to an existing suspension lift.
Our innovative IR Bushings provide unrestricted rotation and flex as well as excellent NVH damping. These maintenance-free bushings improve on- and off-road ride quality and performance.
Must be used with TeraFlex JK: Alpine Long Arm Bracket Kit (# 1957000) – NOT INCLUDED. On higher lifts, Alpine Long Arm Brackets reposition the frame-end control arm mounting points to restore near factory orientation to reduce bushing stress during droop and shock load transferred through the control arms.
CAD-engineered Alpine Long Arm Brackets are designed for maximum strength. By streamlining the frame-end mounting points, we were able to incorporate both upper and lower mounts in each bracket thus simplifying installation while maintaining a factory appearance.
Our innovative IR Bushings provide unrestricted rotation and flex as well as excellent NVH damping. These maintenance-free bushings improve on- and off-road ride quality and performance.
Must be used with TeraFlex JK: Alpine Long Arm Bracket Kit (# 1957000) – NOT INCLUDED. On higher lifts, Alpine Long Arm Brackets reposition the frame-end control arm mounting points to restore near factory orientation to reduce bushing stress during droop and shock load transferred through the control arms.
CAD-engineered Alpine Long Arm Brackets are designed for maximum strength. By streamlining the frame-end mounting points, we were able to incorporate both upper and lower mounts in each bracket thus simplifying installation while maintaining a factory appearance.
Pricing:
$1,968.99
Description
TeraFlex JK: Alpine IR Short Control Arms provide complete alignment adjustability and dependability for maximum performance on JK Wrangler/Unlimited models with 2-4” lifts. Bolts to the factory control arm mounting brackets. Can be added to any existing suspension lift.
Our innovative IR Bushings provide unrestricted rotation and flex as well as excellent NVH damping. These maintenance-free bushings improve on- and off-road ride quality and performance.
FEATURES/BENEFITS
JK Alpine IR Short Control Arms:
• Adjustable Alpine IR Short Control Arms balance front caster angle and pinion angles as well as optimize rear pinion angle and tune anti-squat geometry for proper suspension alignment on 2-4” lift kits
• Alpine IR Short Control Arms are constructed from durable 42mm x 4mm wall DOM tube for maximum strength
• Bolts to the factory control arm mounting brackets
• Install and drive simple bolt-on installation – no welding required
JK Alpine IR Control Arms (all):
• Re-centers axles in the wheel well for proper suspension movement. Can also be used to increase wheelbase
• Full range of movement will not restrict articulation or flex off-road
• Innovative IR Bushings provide unrestricted rotation and flex as well as excellent NVH damping
• Maintenance-free IR Bushings improve on- and off-road ride quality and performance
• Zero maintenance forged threaded joints for smooth quiet flex
• Premium black e-dipped coating on tube and forged rod end housing provides superior durability and corrosion resistance
• Anodized 6061-T6 aluminum clamp collar to secure rod end after length adjustment
• TeraFlex Lifetime Warranty against defects
INCLUDES
Alpine IR Short Control Arms:
• Front Upper (# 1415570) – pair
• Front Lower (# 1415580) – pair
• Rear Upper (# 1415590) – pair
• Rear Lower (# 1415600) – pair
VEHICLE FITMENT INFO
Fits:
• JK Wrangler (2-door)
• JK Wrangler Unlimited (4-door)
• 2-4” Lift
Control Arm Specs:
JK: Alpine IR Short Control Arm Kit – Front Upper (# 1415570):
• Tube Diameter & Wall: 1-5/8” x 0.157” (42mm x 4mm)
• Factory Length = 18-3/4”
• Min. Length = 18-1/2”
• Max. Length = 19-3/4”
• Both Ends = 7/16” (12mm) Bolt
• Thread = 1-1/4”-12 UNF
JK: Alpine IR Short Control Arm Kit – Front Lower (# 1415580):
• Tube Diameter & Wall: 1-5/8” x 0.157” (42mm x 4mm)
• Factory Length = 22-5/8”
• Min. Length = 22-3/4”
• Max. Length = 24”
• Both Ends = 9/16” (14mm) Bolt
• Thread = 1-1/4”-12 UNF
JK: Alpine IR Short Control Arm Kit – Rear Upper (# 1415590):
• Tube Diameter & Wall: 1-5/8” x 0.157” (42mm x 4mm)
• Factory Length = 17-7/16”
• Min. Length = 17-5/8”
• Max. Length = 18-7/8”
• Both Ends = 9/16” (14mm) Bolt
• Thread = 1-1/4”-12 UNF
JK: Alpine IR Short Control Arm Kit – Rear Lower (# 1415600)
• Tube Diameter & Wall: 1-5/8” x 0.157” (42mm x 4mm)
• Factory Length = 19-3/4”
• Min. Length = 19-13/16”
• Max. Length = 21-1/16”
• Both Ends = 9/16” (14mm) Bolt
• Thread = 1-1/4”-12 UNF
PRODUCT NOTES
• Alignment REQUIRED.
RELATED ITEMS
Alpine IR Short Control Arm Configurations:
• 8-Arm Kit (# 1415611)
• Front Upper (# 1415570) – pair
• Front Lower (# 1415580) – pair
• Rear Upper (# 1415590) – pair
• Rear Lower (# 1415600) – pair
• IR Bushing Replacement Kit – 8 Short Control Arms (# 1952700)
INSTALL TIME
5 Hours
Our innovative IR Bushings provide unrestricted rotation and flex as well as excellent NVH damping. These maintenance-free bushings improve on- and off-road ride quality and performance.
FEATURES/BENEFITS
JK Alpine IR Short Control Arms:
• Adjustable Alpine IR Short Control Arms balance front caster angle and pinion angles as well as optimize rear pinion angle and tune anti-squat geometry for proper suspension alignment on 2-4” lift kits
• Alpine IR Short Control Arms are constructed from durable 42mm x 4mm wall DOM tube for maximum strength
• Bolts to the factory control arm mounting brackets
• Install and drive simple bolt-on installation – no welding required
JK Alpine IR Control Arms (all):
• Re-centers axles in the wheel well for proper suspension movement. Can also be used to increase wheelbase
• Full range of movement will not restrict articulation or flex off-road
• Innovative IR Bushings provide unrestricted rotation and flex as well as excellent NVH damping
• Maintenance-free IR Bushings improve on- and off-road ride quality and performance
• Zero maintenance forged threaded joints for smooth quiet flex
• Premium black e-dipped coating on tube and forged rod end housing provides superior durability and corrosion resistance
• Anodized 6061-T6 aluminum clamp collar to secure rod end after length adjustment
• TeraFlex Lifetime Warranty against defects
INCLUDES
Alpine IR Short Control Arms:
• Front Upper (# 1415570) – pair
• Front Lower (# 1415580) – pair
• Rear Upper (# 1415590) – pair
• Rear Lower (# 1415600) – pair
VEHICLE FITMENT INFO
Fits:
• JK Wrangler (2-door)
• JK Wrangler Unlimited (4-door)
• 2-4” Lift
Control Arm Specs:
JK: Alpine IR Short Control Arm Kit – Front Upper (# 1415570):
• Tube Diameter & Wall: 1-5/8” x 0.157” (42mm x 4mm)
• Factory Length = 18-3/4”
• Min. Length = 18-1/2”
• Max. Length = 19-3/4”
• Both Ends = 7/16” (12mm) Bolt
• Thread = 1-1/4”-12 UNF
JK: Alpine IR Short Control Arm Kit – Front Lower (# 1415580):
• Tube Diameter & Wall: 1-5/8” x 0.157” (42mm x 4mm)
• Factory Length = 22-5/8”
• Min. Length = 22-3/4”
• Max. Length = 24”
• Both Ends = 9/16” (14mm) Bolt
• Thread = 1-1/4”-12 UNF
JK: Alpine IR Short Control Arm Kit – Rear Upper (# 1415590):
• Tube Diameter & Wall: 1-5/8” x 0.157” (42mm x 4mm)
• Factory Length = 17-7/16”
• Min. Length = 17-5/8”
• Max. Length = 18-7/8”
• Both Ends = 9/16” (14mm) Bolt
• Thread = 1-1/4”-12 UNF
JK: Alpine IR Short Control Arm Kit – Rear Lower (# 1415600)
• Tube Diameter & Wall: 1-5/8” x 0.157” (42mm x 4mm)
• Factory Length = 19-3/4”
• Min. Length = 19-13/16”
• Max. Length = 21-1/16”
• Both Ends = 9/16” (14mm) Bolt
• Thread = 1-1/4”-12 UNF
PRODUCT NOTES
• Alignment REQUIRED.
RELATED ITEMS
Alpine IR Short Control Arm Configurations:
• 8-Arm Kit (# 1415611)
• Front Upper (# 1415570) – pair
• Front Lower (# 1415580) – pair
• Rear Upper (# 1415590) – pair
• Rear Lower (# 1415600) – pair
• IR Bushing Replacement Kit – 8 Short Control Arms (# 1952700)
INSTALL TIME
5 Hours
Product Series
Details
Shipping Information
- Item Requires Shipping
- 65.8 lbs.
- W13.5000” x H7.0000” x L25.5000”
