Bulldog Control Unit - 8 Circuit Switch System - Bluetooth

20446
Conveniently connects up to 8 component accessories to an under-hood control box with Bluetooth control from your smart phone.

These have a ton of flexibility to customize with different switch modes, background colors, and 80 different switch covers included.

Switch Panel Dimension: 4.5" x 2.75" x .5"
Control Box Dimension: 6.5" x 4.25" x 1.4"
Pricing: $279.99
Qty:
Free Shipping!

Description

The most amazing benefit of having a wirelessly controlled system...

NO NEED TO ROUTE WIRES THROUGH YOUR FIREWALL OR DAMAGE YOUR DASH!

8 channels, 2 x 30 amp, 2 x 20 amp, 2 x 10 amp, and 2 x 5 amp circuits
• Bluetooth control using our iOS and Android mobile app
• Manual buttons for individual circuit power on top of control box
• Voltage protection breaker installed on positive input wire for whole system protection
• Waterproof case design, withstands temps from below freezing to 250 degrees F
• 12v - 24V
• 600 Watt Maximum on 12V, 1200W on 24V. 60 Amp Maximum

Application List

Universal

Details

Categories

Shipping Information

  • Item Requires Shipping
  • 12.0 lbs.
  • W4.0000” x H8.0000” x L5.0000”
  • Free Shipping!
